vp9000 Solder paste Inspection
3D Inspection Solutions for your SPI Applications
System Highlights
- Accurate and Reliable 3D Measurements
- High Speed Inspection
- Quick and Easy Programming
- Intuitive and Interactive User Feedback
- Small Footprint and Integrated Touch Screen Control
Inspection Capabilities
- Full Volumetric and Print Characteristic Inspection
- X/Y Shift with Printer Feedback
- Bridging and Foreign Material
- BGA Coplanarity and PCB Warp Inspection
- Adhesive Print Inspection Compatible
Omron VTS-1080 3d AOI
- 3D Inspection Solutions for your Pre and Post Reflow AOI Applications
- Advanced quad, digital Multi Phase Shift (MPS) 3D projectors
- Multi-Direction Multi-Color (MDMC) Color-Highlight™ illumination
- Quad side-angle inspection cameras
- Full 3D Imaging plus Hybrid-3D for best in class Solder Joint Profiling
- Offline Programming with AI Self-Optimization for intuitive programming
- High-Speed, High-Quality Inspection
- Integrated and Interactive Review and Analysis Too
- Inspection Capabilities
- Patented Hybrid-3D Profiling (True 3D plus 3D Color-Highlight™)
- Real World, IPC-Correlated Inspection Approach
- No Shadow effect; No Secondary reflection
- Advanced PCB Warp and PCB Flex Compensation
- Large board capability up to 20”x26”
- Pre and Post reflow capable
Omron VT-x750 CT AXI
Automated 3D CT Inspection Solutions for your Critical X-Ray Applications
- Fully Automated, In-Line / Off-Line Inspection
- Highest Quality 3D CT X-Ray Imaging Technology
- Fastest 3D CT Inspection Speeds
- PCB Constraint-Free Design Inspection
- Informative and Comprehensive Review Software
Omron 3D CT AXI Solution Inspection Capabilities
- Up-to 400 slices of Vertical X-Ray Resolution
- Simultaneous Top and Bottom PCB Surface Inspection
- Comprehensive and Advanced BGA Inspection
- High Quality and Reliable HiP Inspection Capability
- Full THT Inspection Including True Barrel-Fill
- Inspection Tools for SMT, PoP, THT and Press-Fit Components
Q-upNavi Quality Control SW
- Side-by-Side Image Comparison from Multiple Inspection Machines
- Live Process Monitoring Charts
- Detailed Quality and Control Analysis for Each Inspection
- Automatic Reporting With the Ability to Separate by Shift, Program, Part, Date, Defect, etc.
- Simplifies True Root-Cause Analysis
- Automatically Grabs Data from Omron SPI, AOI and AXI systems
- Accessible Through a Web Interface from Any PC Connected to the Network
